High Quality Luxury Durable Pre Engineered Steel Buildings House From China
- Model:QB42
- Floor:2
- Width↑: 16.14m
- Length→: 13.44m
- Floor Area: 200㎡
- Building Area:401㎡
- Rooms Qty:5
High Quality Luxury Durable Pre Engineered Steel Buildings House From China - QB42
| Product Photo |
We are now offering a high-performance prefab steel structure on sale. This structural system features a light self-weight (50~60kg/sqm) and high strength, with a floor load capacity of 150kg/sqm, roof load capacity of 60kg/sqm, and external wall load capacity of 50kg/sqm, demonstrating excellent stability.
| Detail |
| No. | NAME | DESCRIPTION | UNIT | THEORY QTY | LOSS RATE | UNIT | ACTUAL QTY |
| 一 | LGS Structure | ||||||
| 1 | steel structure | ㎡ | 401 | 1.00 | T | 16.04 | |
| 2 | fittings | set | 401 | 1.00 | ㎡ | 401.00 | |
| 二 | Wall System | ||||||
| 1 | External wall OSB board | 1220*2440*9mm | ㎡ | 396.84 | 1.30 | pc | 179 |
| 2 | External wall unidirectional breath paper | ㎡ | 396.84 | 1.30 | m2 | 516 | |
| 3 | External wall wooden support | 30*40*3000mm | m | 1190.52 | 1.30 | pc | 516 |
| 4 | External wall metal carved board | 381*3800*16mm +381*4500*16mm | ㎡ | 396.84 | 1.30 | ㎡ | 516 |
| 5 | Internal wall OSB board | 1220*2440*9mm | ㎡ | 669 | 1.30 | pc | 302 |
| 6 | Internal wall PVC board | 1200*2400*9mm | ㎡ | 669 | 1.20 | m2 | 803 |
| 7 | Wet district fiber cement board | 1220*2440*10mm | ㎡ | 169.8 | 1.30 | pc | 77 |
| 三 | Insulation System | ||||||
| 1 | Glasswool Insulation | T75mm，12㎡/roll 16Kg/m3 | ㎡ | 617.82 | 1.30 | m2 | 803 |
| 2 | Glasswool insulation(under roof) | T75mm，12㎡/roll 16Kg/m3 | ㎡ | 216 | 1.30 | m2 | 281 |
| 3 | External wall XPS board | 1200*600*40mm | ㎡ | 396.84 | 1.20 | pc | 661 |
| 四 | Floor System | ||||||
| 1 | Floor surface OSB | 1220*2440*18mm | ㎡ | 205 | 1.30 | m2 | 267 |
| 2 | Floor self-paste waterproof coil | T1.5mm，-15℃，20㎡/roll | ㎡ | 205 | 1.20 | roll | 12 |
| 3 | Floor tile | 12mm | ㎡ | 205 | 1.10 | ㎡ | 226 |
| 五 | Roof System | ||||||
| 1 | Roof OSB board | 1220*2440*12mm | ㎡ | 216 | 1.50 | pc | 113 |
| 2 | self-paste waterproof coil | T1.5mm，-15℃，20㎡/roll | ㎡ | 216 | 1.40 | roll | 15 |
| 3 | Roof tile | asphalt tile | ㎡ | 216 | 1.50 | pack | 116 |
| 4 | Roof ridge tile | asphalt tile | m | 100 | 1.10 | pack | 14 |
| 5 | Roof eaves pvc molding | 6m/pc | m | 60.36 | 1.50 | pc | 15 |
| 6 | PVC closing strip | 4m/pc | m | 60.36 | 1.50 | pc | 23 |
| 7 | Metal carved board under roof eaves | 381*3800*16mm | ㎡ | 36.216 | 1.50 | pc | 38 |
| 六 | Ceiling | ||||||
| 1 | pvc ceiling | 6000*200mm | ㎡ | 401 | 1.20 | ㎡ | 401.00 |
| 2 | pvc angle skirting | ㎡ | 401 | 1.05 | ㎡ | 421.05 | |
| 七 | Door & Window | ||||||
| 1 | Alumunium double glaze window | ㎡ | 88.4 | 1.00 | ㎡ | 88.40 | |
| 2 | Steel and MDF door | ㎡ | 16 | 1.00 | ㎡ | 16.00 | |
| 八 | Water&Electric System | ||||||
| 1 | Water Pipes | ㎡ | 401 | 1.00 | ㎡ | 401.00 | |
| 2 | Electric system | Include weak current,exclude socket/switch/light,etc | ㎡ | 401 | 1.00 | ㎡ | 401.00 |
| 九 | Accessories System | ㎡ | 401 | 1.00 | ㎡ | 401.00 | |
| 十 | Loading | ㎡ | 401 | 1.00 | ㎡ | 401.00 |
| Technical Parameters | |
| Overall weight | 50~60kg/sqm |
| Seismic fortification intensity | 8 grade |
| Wind-proof capacity | wind speed 20m/s, resist 8 grade wind |
| Floor loading capacity | 150kg/sqm |
| Roof loading capacity | 60kg/sqm |
| External wall bearing capacity | 50kg/sqm |
| Packing & Shipping |
Choosing manufacturing in China means accessing top-tier customized solutions, which is the core advantage of our custom prefab house in china. Our buildings can withstand a seismic fortification intensity of 8 degrees and wind speeds of 20m/s (Grade 8 wind), ensuring safety and durability in various environments.
