40ft shipping containers for sale
- Dimension
- External Dimensions Internal Dimensions
- Length 12,192 ( 0, -10 ) mm 12,032 ( 0, -10 ) mm
- Width 2,438 ( 0, -5 ) mm 2,352 ( 0, -5 ) mm
- Height 2,896 ( 0, -5 ) mm 2,698 ( 0, -5 ) mm
Technical Specification For 40' x 8' x 9'6" ISO Type Dry Cargo Steel Container
5 . Dimensions and Ratings
5.1 Dimension
External Dimensions
Internal Dimensions
Length
12,192 ( 0, -10 ) mm
12,032 ( 0, -10 ) mm
Width
2,438 ( 0, -5 ) mm
2,352 ( 0, -5 ) mm
Height
2,896 ( 0, -5 ) mm
2,698 ( 0, -5 ) mm
No part of the container will protrude beyond the external dimensions
mentioned above.
Maximum allowable difference between two diagonals on any one of the
following surface are as follow:
Roof, Bottom and Side Diagonals.......... 19 mm.
Front and Rear Diagonals.......... 10 mm.
5.2 Door Opening
Width ..................2,340 ( 0,-5 )mm
Height ...................2,585 ( 0,-5 )mm
5.3 Gooseneck Tunnel
Length ..................3,315mm
Width ..................1,029 ( +3,0 )mm
Height ...................120 ( 0,-3 )mm
5.4 Inside Cubic Capacity
76.4 cu.m 2,700 cu.ft
5.5 Rating
Maximum Gross Weight ..............32,500 kg 71,650 lbs
Maximum Payload .............28,670 kg 63,210 lbs
Tare Weight (±2%) ...............3,830 kg 8,440 lbs
